Imet BS 350 SHI Bandsaw
The BS 350 SHI is a heavy-duty hydraulic, semi-automatic bandsaw with mitre cutting capabilities ranging from 0° to 60° on the right and from 0° to 45° on the left. It is highly recommended for production situations, particularly when cutting square sections or flat bars. This is due to its unique below centre pivot point, which causes the blade to be inclined at the end of the cut, offering the line of least resistance for these materials. The advantages of this design are faster cut times, longer blade life, a wider range of materials that can be cut with each blade pitch, and reduced stress on the machine components. It is important not to underestimate the significance of this feature, combined with the robust construction and high-quality components, all of which contribute to making the BS350 a leading product in its class.
The bandsaw features hydraulic semi-automatic operation and allows for mitre cutting from 0° to 60° on the left and from 0° to 45° on the right. It is equipped with a hydraulic vice that has adjustable guides, allowing it to move freely alongside the worktable. The vice also offers quick motion and clamping capabilities. Convenient stops are available at 0°, 45°, 60° on the left, and 45° on the right. The blade tension can be adjusted from the front side of the sawframe and can be checked using an end-stroke mechanism. The blade guides are equipped with hard metal pads and an additional bearing for blade alignment.
The sawframe is constructed from steel with a tubular section and features pulleys with a diameter of 360 mm. A mechanical device, known as a position sensor, enables the sawframe to lower quickly toward the material and automatically detect the starting point of the cut. The cutting capacity of the BS350 is as follows: up to 255 mm for rounds, up to 240 mm for squares, and up to 300×180 mm for rectangular pieces.
- Hydraulic vice with adjustable guides, free to move alongside the worktable, with quick motion and clamping.
- Easy stops at 0°, 45°, 60° left and 45° right. Adjustment of the blade tension from the front side of the sawframe, checked by an end-stroke. Blade guides with hard metal pads, additional bearing for blade alignment.
- Steel sawframe with tubular section, pulleys 360 mm diameter.
- Mechanical device (position sensor) that allows the sawframe to lower quickly toward the material and detect automatically the start-cut point.
- Cutting Capacity: rounds till 255 mm., square till 240 mm. and rectangular till 300×180 mm.
Electronic variable speed control: 18-100 m/min
Hydraulic Vertical Vice (for bundle cutting)
This hydraulic device is designed for cutting bundles.
- Maximum dimensions: 230x160mm
- Minimum dimensions: 90x10mm
This bandsaw is equipped with a pure oil micro-mist blade lubrication system. It is recommended for cutting tubes and sectional materials where the loss of flood lubricant through the material is an issue. This precise delivery system allows for adjustment of the number of pulses per minute and the quantity of each dose. Please note that a compressed air supply is required.
The standard flood system is still available for cutting solid materials, and the operator can easily switch between the two systems.
This hydraulic vertical vice is specifically designed for unloading from the side only.
Powered Laser Line
This item is factory-fitted by Imet.
Battery Laser Line
This high-quality German battery laser line is an Addison fit item.
Roller Tables & Options
Connecting element for roller table for the unloading side.
RTSPRW40 Roller Table
Loading / unloading roller table. 1st element length 2m, capacity 700kg.
RTSSEW40 2000mm extension table available
RTMPRW40 Manual Measuring Table
Unloading roller table with metric rod, measurement feedback. 1st element, length 2mt , capacity 700kg
RTMSEW40 2000mm extension table available
RTP3W40 NC Measuring Table
3000mm NC servo drive measuring table. 5.7″ Touch screen HMI for cutting data input. Up to 20 different cutting lengths. Automatic 50mm retreat function to allow easy unloading of the cut piece.
RTD2LW40 Manual Digital Measuring Table
2000mm Manual positioning with handwheel and digital display of the cutting length. Pneumatic locking on position and 50mm retraction to allow easy unloading of the cut piece.
R1-W30 Vertical Rollers
Pair of containment vertical rollers 300 mm, made in steel max 2 pairs for each element 2m long, to use without rollers cover (only for RTS )
