Cutting Capacity:
Round Material Tube: 75 mm 90 deg – 65 mm 45 deg
Round Material Solid: 30 mm 90 deg – 30 mm 45 deg
Round Material Tube: 65 mm x 65 mm 90 deg – 55 mm x 55 mm 45 deg
Rectangular material Tube: 80 mm x 50 mm 90 deg – 60 mm x 50 mm 45 deg
Machine Details:
Motor power: 1hp single ph – 2hp 3ph
Blade diameter: 250 mm x 32 mm bore
Blade speed (1ph): 45 rpm
Blade speed (3ph): 45/90 rpm
Max vice opening: 100mm
Machine Weight: 110 kg
Width: 920 mm
Height: 1600 mm
Depth: 880mm
