features;
- 2 speed motorised raise and lower of thickness bed
- Automatic setting of thickness by digital controller
- Length of thickness bed 1200mm
- Feed system with 1 x grooved infeed roller and 2 x steel outfeed rollers
- Automatic star/delts switching
- Electromagnetic brake
- Electronically controlled feed speed 4-19 m/min
- 4 knife cutter block
- 4 point locking system of thickness bed
| A530 | A630 | A800 | ||
|---|---|---|---|---|
| Cutter block diameter | mm | 120 | 120 | 150 |
| Number of cutters | ks | 4 | 4 | 4 |
| Length of cutter block | mm | 550 | 650 | 820 |
| Speed of cutter block | n/min | 4800 | 4800 | 4800 |
| Cutter block dimension | mm | 550 x 35 x 3 | 650 x 35 x 3 | 820 x 35 x 3 |
| Max. height of thicknessing | mm | 300 | 300 | 300 |
| Max. width of thicknessing | mm | 530 | 630 | 800 |
| Max. removal thicknessing | mm | 7 | 7 | 7 |
| Main motor power | kw | 5,5 | 7,5 | 11 |
| Motor power of feeding | kw | 1,1 | 1,1 | 1,5 |
| Feeding speed | m/min | 4.-19 | 4.-19 | 4.-19 |
| Supply / frequence | V/Hz | |||
| Length of worktable | mm | 1200 | 1200 | 1200 |
| Machine length | mm | 1250 | 1250 | 1250 |
| Machine width | mm | 1050 | 1150 | 1320 |
| Machine height | mm | 1222 | 1222 | 1222 |
| Weight | kg | 1020 | 1160 | 1380 |
Options
- Tersa cutterblock
- Increased motor power
- Sectional infeed roller
- Rollers in thickness bed
